| Operation Concept |
Stereo microscope,Greenough design with 5:1 zoom range |
Stereo microscope,Greenough design with 8:1 zoom range |
| Main Component |
Lens body,Stand and Illumination |
Lens body,Stand and Illumination |
| Lens body |
Stemi 305(binocular, incl.eyepieces 10x/23 Br. foc),Stemi 305
doc(Phototube, incl.eyepieces 10x/23 Br. foc) |
Stemi 508(binocular, incl.eyepieces 10x/23 Br. foc),Stemi 508
doc(Phototube, incl.eyepieces 10x/23 Br. foc) |
| Stands |
Ergonomic design with adjustable in height and inclination for longer
use |
Ergonomic design with adjustable in height and inclination for longer
use |
| Input Power Supply |
110 - 240 Volt AC,60/50 Hz |
110 - 240 Volt AC,60/50 Hz |
| Optical data of the Basic and Optional
System |
| Magnification Range |
8x to 40x with basic version(10x eyepieces,no front optics)all
magnifications from 4x to 200x (interchanable optics) |
6.3x to 50x with basic version(10x eyepieces,no front optics)all
magnifications from 2x to 250x (interchanable optics) |
| Maximum Resolution |
200lp/mm basic version:up to 400lp/mm with interchanable optics |
225lp/mm basic version:up to 450lp/mm with interchanable optics |
| Maximum object field |
29 mm basic version;up to 58 mm using interchanable |
36 mm basic version;up to 122 mm using interchanable |
| Working distance |
110 mm basic version;up to 58 mm using interchanable optics |
92 mm basic version;up to 122 mm using interchanable optics |
| Stand |
| Body |
Light weighted aluminium body |
| Focusing |
Manual coarse adjustment with Tilting arm |
| Illumination |
| Dark-field illumination |
Light weighted aluminium body |
